JBL Club 194T 3/4-Inch Dome Tweeter - 50W RMS

Club coaxial and component speakers bring JBL pro sound to more vehicles. Their compact design means they’ll fit into more vehicles than many of our competitors, and their high sensitivity delivers outstanding performance even with modestly-powered factory systems. Rugged polypropylene cones with the Plus One design deliver hard-hitting bass and long performance life. Edge-driven silk dome tweeters deliver broader and smoother high frequency response, never-harsh regardless of output level. Starfish Tweeter Mounting Adapter and I-Mount Tweeter Mounting Kit in component speaker system for easy installation.

• Plus One Woofer Cone Architecture
• Edge-driven Silk Dome Tweeter
• Specified Shallow Design for More Mounting Application
• Adjustable Tweeter Output Level
• Acoustically Damped, UVresistant Polypropylene Cone
• Bigger Magnet, Bigger Power Handling
• Special Tweeter Pod Design for Acoustic Adjustment on Different Listening Position
• Starfish Tweeter Mounting Adapter  I-Mount Tweeter Mounting Kit

Starfish  Tweeter Mounting Adapter

The Club 64C, Club 64CTP component Speaker system come with the Starfish™ tweeter mounting adapter. The Starfish tweeter mounting adapter allows for easy installation of the tweeter behind factory grilles and in locations such as A-Pillar. It also provides six break-off mounting tabs to accommodate many mounting configurations. The tweeter can be surface- or flush-mounted. The tweeter can be easily serviced, and doesn’t require removing the whole assembly.

I-Mount Tweeter Mounting Kit

The I-Mount tweeter-mounting system allows easy and versatile installation of tweeters in each of the component systems. It includes a flush cup and surface-mount mounting hardware. With a 1-3/4″ cutout and a 1″ mounting depth, installation becomes a snap. This allows the tweeter to be flush-mounted and can be angled up to ±40 degrees. Locknuts are included to keep everything in place, and the tweeter can be replaced without removing the whole assembly.

What’s Included?

• 2x Tweeters
• 2x Flush-mount cups
• 2x Threaded flush-mount
• adapters
• 2x Surface-mount cups
• 2x Starfish tweeter mounts
• 2x Plastics locking nuts
• 6x Screws
• 2x In-line crossover pigtail
• 2x Spacers
• 2x Washers

Specifications

Size: 3/4” (19mm)

Type: Edge-Driven Dome Tweeter

Power Handling: 50W RMS, 150W peak

Sensitivity (@ 2.83V): 92dB

Frequency Response: 3kHz – 20kHz

Nominal Impedance: 3.0 ohms
